SMC copper cabinet from China manufacturer - NINGBO TAEPO Communications Co., Ltd.

Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: TP-1803-2400

Packing: carton

Brand Name: TAEPO / OEM / Neutral

Material: SMC

Means of Transport: Ocean,Land;Courier

Delivery Date: 7-14 days

Category: Copper communications

Capacity: 1200 pairs and 2400 pairs

It is used outdoor and for copper cables.

Outdoor 1200 pairs and 2400 pairs SMC housing copper cabinet for LSA module with base

Technical Parameters

1) Working temperature: -40℃ ~ 80℃

2) Relative humidity: ≤93%(+40℃)

3) Appearance: the color of all metal and plastic parts is uniform, without any scratch, rust, crusting and cracks.

4) The labels are clear and complete.

5) Insulation resistance: under normal ambient conditions, after high temperature test, low temperature test, temperature varing test and humidity heat test, the insulation resistance between any two independent contacts, and/or between contacts and metal parts ≥ 1000MΩ

6) Contact resistance between contacts: under normal ambient conditions, the contact resistance between contacts ≤7 mΩ. After high temperature test, low temperature test, temperature varing test and humidity heat test, the increasing resistance ≤3 mΩ And after inserting the connection cord (or test cord) into the module for 200 times, the increasing resistance ≤3 mΩ

7) Contact resistance between conductor and contact: under normal ambient conditions, the contact resistance between contacts ≤3 mΩ. After high temperature test, low temperature test, temperature varing test and humidity heat test, the increasing resistance ≤2 mΩ. And after terminating for 200 times, the increasing resistance ≤2 mΩ.

Descriptions

1) Outdoor SMC copper cabinet is used for the cross connection and terminations between trunk cable and the distribution cables.
2) It is also called Cross Connection Cabinet (CCC).
3) It is used outdoor and for copper cables.
4) It is made of SMC material.
5) It is installed with stainless steel back mount frames, suitable for LSA disconnection modules.

Outdoor 1200 pairs and 2400 pairs SMC housing copper cabinet for LSA module with base

Order Data

ITEM NO	UNIT	DESCRIPTIONS
TP-1803-1200	pcs	Outdoor1200 pairs copper cabinet, SMC housing, for LSA module, with base, with backmount frame, without LSA module
TP-1803-2400	pcs	Outdoor2400 pairs copper cabinet, SMC housing, for LSA module, with base, with backmount frame, without LSA module
