1 pair MDF protector
Payment Terms: |
T/T,L/C,WU |
Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
TP-1507-1
Production Capacity:
A large number of
Delivery Date:
7- 14 days
Category:
Copper communications
Capacity:
1 pair
Function:
for MDF terminal block
Relative humidity:
≤85% (+30℃)
Transverse voltage duration:
≤200ns
Means of Transport:
Ocean,Land,Air;Courier
Packing:
inner box + carton
Brand Name:
TAEPO / OEM / Neutral
Material:
ABS
Color:
Orange or blue
Dimension:
68x8x7mm
Fail-safe response time:
≤15s
Nominal DC spark-over voltage (100V/s):
230±20% V
For this protector, the outside line directly collides against a 220 V power line.
1 pair MDF protector for MDF terminal block # TP-1407-100
Order Data
ITEM NO | UNIT | DESCRIPTIONS |
TP-1507-1 | pcs | 1 pair MDF protector for MDF terminal block # TP-1407-100 |
1 pair MDF protector for MDF terminal block # TP-1407-100
Main Features
Modular single pair design
Easy installations
Maintenance free
Graded 5 point protection
Fail Safe (FS) function
Descriptions
TP-1506-1 MDF protector is used for LSA modules, which forms the protection circuit for the protection of exchange room equipments and personnel against over voltage and over current, for mainly as follows:
1) The surge voltage caused by lightning on or around the outside lines.
2) The short-time AC voltage inducted on external lines, when the power line, the power system or the electric railway system is broken down in the neighborhood of the outside line.
3) The outside line directly collides against a 220 V power line.
4) The housing of the protector is flame retardant, high temperature resistance and aging resistance. It is 1 pair modular design protector.
![](http://img.hisupplier.com/var/userImages/2012-08%2F31%2F094601817208.jpg)
