25 Pairs NT wiring block Test cord

Descriptions

TP-1303-25 NT wiring block is 25 pairs, providing high density wire termination for voice and data communications wiring applications. The combination of labeling options and easy installation makes for an ideal cross-connection solution.

TAEPO's solution employ a contact design which feeds the signal straight through the module for a solid, reliable connection.

Installation is a simple process. Insertion tool # TP-5911 is only tool needed to terminate the wires to the module.

The straight through design of 25 pairs NT wiring block provides the highest density available. Plus, the NT wiring block maintains full Category 5 compliance.

The NT wiring block gives you unsurpassed reliability and durability.

TAEPO's NT wiring block meets Category 5 (100MHz) standards for connecting hardware as specified by EIA/TIA bulletin TSB-40 and ISO 11801.

Main Features

Insulation Displacement Connection

No Wire-stripping, screw and solder free

Reliable connections

Clear labeling

Flame retardant performance

Modular design and installations

Gas tight connection

Two wires per contact

One push wire insertion

Only one inexpensive tool required

Technical Parameters

Working temperature: -40℃ ~ 80℃

Relative humidity: ≤93%(+40℃)

Appearance: the color of all metal and plastic parts is uniform, without any scratch, rust, crusting and cracks.

The labels are clear and complete.

Insulation resistance: under normal ambient conditions, after high temperature test, low temperature test, temperature varing test and humidity heat test, the insulation resistance between any two independent contacts, and/or between contacts and metal parts ≥ 1000MΩ

Contact resistance between contacts: under normal ambient conditions, the contact resistance between contacts ≤7 mΩ. After high temperature test, low temperature test, temperature varing test and humidity heat test, the increasing resistance ≤3 mΩ And after inserting the connection cord (or test cord) into the module for 200 times, the increasing resistance ≤3 mΩ

Contact resistance between conductor and contact: under normal ambient conditions, the contact resistance between contacts ≤3 mΩ. After high temperature test, low temperature test, temperature varing test and humidity heat test, the increasing resistance ≤2 mΩ. And after terminating for 200 times, the increasing resistance ≤2 mΩ.

Dielectric strength: under normal ambient conditions, after high temperature test, low temperature test, temperature varing test and humidity heat test, the insulation resistance between any two independent contacts, and/or between contacts and metal parts is able to withstand an AC voltage of 1000V (virtual value) at 45Hz~60Hz sinowave for 1 minute, without spark over and flying arc

Gas tight performance: contact touches the conductor at both sides, and thus forming the gas tight area, while the area of gas tight occupies ≥50% of the touched area on each side.

Conductor diameter range: 0.32mm-0.6mm, while insulation ≤ 1.4mm

Pulling strength:≥25N while pulling from the vertical side of the contacts

Flame retardant performance: all plastic parts are flame retardant, reaching grade of UL FV0

Life circle: ≥200 times
